Upper link molding convyorDirectly injection process

Upper Link Molding Conveyor with 60 Work Stations

JG1101

Features:

The price for
Price:0-15200

Features:

1. Three ways of heating are adopted, that is, electric heating, fuel heating and oil-electricity heating at the same time, which can be applied to the supply of different energy sources, and can also choose different energy sources independently.(this item machine is electric heating)
hen the price and supply of a certain kind of energy in the user's place is absolutely superior, or when one heating method needs to be overhauled and another heating method must be started for production without stopping, our machine shows unique adaptability.
Our machine is available for users to choose low-cost heating method. If the low valley electricity heating cost is lower than the fuel oil heating, namely chooses the low valley electricity heating; Fuel oil heating costs less than peak electricity heating, that is, the choice of fuel heating.
2. This product can open two heating modes at the same time, which improves the heating speed and temperature.
3. The conversion of different heating mode, bake, still can guarantee the working temperature uniformity error ≦ 10 ℃


Parameter:

Speed adjusting way of driving electromagnetism speed adjusting, frequency conversion speed adjusting.
Adjusting range of mould tray’s operating line speed 0-12 m/min
Adjusting range of drying tunnel operating temperature Room temperature-80
Equality difference of drying tunnel working time 10
Max variable height of mould 420mm
Work Stations 60
Dimensions (L*W*H) 18.96*2.45*2.12M (mould plate: 600*500mm)
Sections of drying tunnel 7(900*650mm)
Heating system Electricity
Power 53.5kw
